The sun's path over NSW changes through the year, and the direction and angle of your panels decide how much of that light they catch. Here is the geometry behind north-facing, east-west and flat-roof layouts, explained simply. In NSW, panels facing true north at a moderate tilt catch the most sunlight over a year, but the penalty for other layouts is smaller than many people expect. East and west-facing panels, low-pitched roofs and near-flat installations can all perform well, because what matters is how the sun's path lines up with the panel surface through each day and season. The geometry is not complicated once three things are clear: your latitude, the tilt of the Earth's axis, and the angle at which sunlight strikes the panel.
Latitude and the height of the sun
A panel produces the most when sunlight strikes it square-on, because the beam is concentrated on the smallest area. The further the light is from perpendicular, the less energy lands on each square metre, roughly following the cosine of the angle of incidence.
How high the sun climbs depends on latitude. Sydney sits at about 34 degrees south, and because the Earth's axis is tilted by about 23.4 degrees, the midday sun's height changes through the year:
| Date (approximate) | Midday sun elevation in Sydney | What it means for panels |
|---|---|---|
| Summer solstice, around 22 December | About 80 degrees, nearly overhead | Flat and low-tilt panels receive near-perpendicular light |
| Equinoxes, around 20 March and 23 September | About 56 degrees | A panel tilted near 34 degrees faces the noon sun almost directly |
| Winter solstice, around 21 June | About 33 degrees, low in the north | Steeper panels catch the low winter sun better |
Other parts of the state differ only slightly. Newcastle is about a degree further north and the Canberra region a little further south, so the sun sits marginally higher or lower. The principle is the same across NSW.
The sun's daily path through the seasons
Height is only half the picture. The sun's direction through the day also shifts:
- Summer: the sun rises south of due east, arcs high across the northern sky and sets south of due west. Days are long, and early and late light arrives from the south-east and south-west.
- Autumn and spring: the sun rises close to due east and sets close to due west, with day and night of similar length.
- Winter: the sun rises north of east, stays low in the northern sky and sets north of west. Days are short, and anything to the north casts long shadows.
This is why a south-facing panel in NSW still produces reasonably in summer but very little in winter, and why a tree or building that casts no shade on a roof in December can shade it for hours in June.
Tilt: steeper, flatter or in between
For a north-facing panel, a tilt close to the latitude gives the best balance across the year. In practice the optimum for annual output is broad: tilts from around 15 to 35 degrees on a north-facing roof deliver similar yearly totals, with steeper angles favouring winter and flatter ones favouring summer. Most pitched roofs fall within a workable range, which is why panels are usually mounted flush with the roof.
Changing tilt shifts production between seasons more than it changes the annual total. That shift matters when:
- winter usage is high, for example in homes with electric heating, where steeper panels help;
- a system supports a backup or standalone battery that must keep charging in winter;
- summer air-conditioning dominates, where flatter panels line up with the load.
North versus east-west layouts
Orientation is described by azimuth, the compass direction a panel faces. One detail is often missed: layouts should be assessed against true north, not magnetic north. In Sydney, magnetic north lies more than ten degrees east of true north, which is enough to skew a quick estimate made with a compass.
North-facing panels produce the largest annual total, with a production curve that peaks around solar noon. East and west-facing panels trade some annual energy for a wider curve: east panels ramp up early and west panels keep producing later into the afternoon. An east-west split typically produces somewhat less over a year than the same capacity facing north, often in the order of 10-20% less depending on pitch, with the smallest penalty on low-pitched roofs. The idea that panels only work facing north is one of the common solar misconceptions.
| Layout | Production shape | Often suits |
|---|---|---|
| North | Tall midday peak, highest annual total | Most homes, especially with daytime loads or a battery to shift energy |
| East-west split | Lower, broader curve from morning to late afternoon | Morning and afternoon usage, roofs without a north face, export-limited connections |
| West only | Production shifted later towards the evening | Late-afternoon cooling loads or time-of-use pricing |
| South, low pitch only | Reduced output, weak in winter | Adding capacity on very flat roofs when other faces are full |
Because production timing affects how much solar a home uses directly, the value of a layout depends on the household as much as the geometry. The link between timing and price is covered in understanding time-of-use tariffs, and the conversion from sunlight to household power in how solar power works.
Flat roofs: near-flat or tilt frames?
On flat roofs, designers choose between laying panels almost flat and raising them on frames. Each option has trade-offs:
- Near-flat: strong summer output, weaker winter output, more panels in a given area because rows do not shade each other, and lower wind loads. A small minimum tilt, commonly around 10 degrees, helps rain wash dust off and stops water pooling along the frame.
- North-facing tilt frames: better winter production and a higher annual yield per panel, but rows must be spaced so they do not shade each other when the winter sun is low, and frames catch more wind.
- Low-tilt east-west rows: panels leaning back to back fit densely, keep wind loads down and give a broad production curve.
Row spacing is normally checked against the low midwinter sun, since a layout that is shade-free in June will be shade-free for the rest of the year. The common rule of thumb that a 6.6 kW system in Sydney produces roughly 24-27 kWh a day on average assumes a reasonable orientation; a site-specific estimate accounts for your actual tilt, azimuth and shading.
Next steps
Tilt, orientation and shading are best measured on site rather than guessed from an aerial photo. The Solar-Ready Roof Assessment ($199 per property, credited) and the Arborist & Shading Assessment (from $450 per property) are listed in the energy market. Prices are indicative and confirmed after a site assessment. For a layout designed around your roof faces and daily usage, request a free assessment from Blue Energy Solar.
Frequently asked questions
Are sun-tracking mounts worth it for a home?
Trackers turn panels to follow the sun and can raise output per panel, but they add moving parts, maintenance and structural cost, and they rarely suit roofs. For most homes, adding another panel or two on a fixed mount delivers extra energy more simply. Tracking is mainly considered for some ground-mounted rural or commercial arrays where space and service access allow.
Does orientation affect how much a system can export?
It can. Where an export limit applies, a north-facing array may reach the limit around midday on sunny days, and output above it is curtailed. An east-west layout spreads production across more hours, so less may be cut off at the peak. The effect depends on array size, inverter capacity, household usage during the day and the limit set for the connection.
How can I find my roof's orientation without climbing up?
Online satellite maps show roof faces clearly and usually place true north at the top, which avoids the magnetic compass error. You can also watch the midday sun: at solar noon it sits due north everywhere in NSW. Treat either method as a rough guide. A professional assessment measures pitch and azimuth accurately, so there is never a need to go onto the roof yourself.
